Hastelloy N/Hastelloy X/Hastelloy W/Hastelloy S Nickel Plate/Sheet/Strip Price in Stock

Basic Info.

Model NO.	Hastelloy N/Hastelloy X/Hastelloy W/Hastelloy S
Purity	Min 72%
Alloy	Alloy
Type	Nickel Plate
Powder	Powder
Thickness	0.2-100mm
Width	Normally 1000mm/1219mm/1500mm
Length	Normally 2000mm/2438mm/6000mm
Mtc	En 10204/3.1
Keyword	Inconel 600 Nickel Alloy Plate
Trademark	ZYTC
Origin	Tianjin, China
HS Code	75062000
Production Capacity	500 Tons/Month

Product Description

Hastelloy N (UNS N10003) is a nickel based alloy which as a container material for molten fluoride salts. It has good oxidation resistance to hot fluoride salts in the temperature range of 704-871ºC.
Hastelloy N Specifications: Hastelloy N Product Forms and Standards: HASTELLOY S alloy (UNS N06635) is a nickel-base, high-temperature alloy with a unique combination of properties. It has excellent thermal stability, low thermal expansion and excellent oxidation resistance to 2000°F (1093°C). In addition, the alloy has good high-temperature and thermal fatigue strength. S alloy retains its strength and ductility after aging at temperatures of 800 to 1600°F (427 to 871°C).S alloy was developed for applications involving severely cyclical heating conditions where components must be capable of retaining their strength, ductility, and metallurgical integrity after long-time exposure. It is used extensively as seal rings in gas turbine engines where its low thermal expansion coefficients is also important.
Hastelloy W alloy (UNS N10004) is a solid-solution-strengthened super alloy that was developed primarily as a filler metal for welding of dissimilar alloys. It displays excellent dissimilar welding characteristics, and is widely used for that purpose in the gas turbine and aerospace industries. The properties of dissimilar weld joints made with alloy W are dependents upon the alloys joined, but are generally acceptable for a wide variety of combinations. Alloy W is also used as a wrought alloy for a limited number of ring-type Applications in older gas turbine engines. Haynes 242 alloy is a more modern alloy, and should be considered as a substitute for alloy W in these ring Applications.
Hastelloy W Specifications: The Hastelloy X nickel alloy, with higher iron content, has favorable resistance to oxidation and corrosion combined with excellent creep and rupture strength at temperatures under 900ºC. In addition to this, Hastelloy alloy X has great fabricability by cold and hot working and good weldability.

1. High degree of oxidation resistance up to 2200° F
2. Outstanding high-temperature strength
3. Easily fabricated including forming and welding
4. Good ductility after prolonged exposure at high-temperatures
5. Good resistance to chloride stress-corrosion cracking
6. Resistant to carburization and nitriding
7. Develops a protective oxide film that does not spall off

Hastelloy X Product Forms and Standards:

Hastelloy N Chemical Compositions:

Hastelloy S Chemical Compositions: Hastelloy W Chemical Compositions: Hastelloy X Chemical Compositions:

Hastelloy N Mechanical Properties (RT, Annealed)

Hastelloy W Mechanical Properties (RT, Annealed) Hastelloy X Mechanical Properties (RT, Annealed)

Hastelloy N Applications:Hastelloy N is used in chemical process equipment and general industrial applications requiring high temperature oxidation resistance.
Hastelloy W Applications:Hastelloy W is widely used for that purpose in gas turbines, aerospace and chemical process industries.
Hastelloy X Applications: This oxidation resistant alloy can be used for combustor components and other high temperature parts of aircraft engines, for long term use at temperature under 900ºC and short time use up to 1080ºC.

1. Gas turbine engines
2. Transition ducts
3. Combustor cans
4. Spray bars and flame holders
5. Afterburners, tailpipes, and cabin heaters
6. Chemical processing retorts, muffles, and tubing

Q: What kind of ZYTC company? A: ZYTC is a professional manufacturer of metals and alloy productions and has its own warehouse with more than 30,000 tons capacity. We are working hard to open up the international market. At the same time, we will encounter a variety of purchase orders, In order to meet customer requirements and improve services, we will also distribute some kinds of metal products, of course, our strict procurement management and quality management departments can guarantee excellent quality of all products.Q: What certificate does ZYTC have? A: ZYTC acquired the ISO 14001 environmental management system certificate, 0HSAS18001 occupational health and safety management system certificate, and ISO 9001 quality management system certificate.Q: What's your purchasing system? A: Our procurement system adopts the 5R principle to ensure the "right quality" from the "right supplier" with the "right quantity" of materials at the "right time" with the "right price" to maintain normal production and sales activities. At the same time, we strive to reduce production and marketing costs to achieve our procurement and supply goals: close relationships with suppliers, ensure and maintain supply, reduce procurement costs, and ensure procurement quality.Q: Who are your cooperate partners? A: ZYTC has a very good relationship with world-known factories, such as Baosteel, TISCO, ZPSS, JISCO, ATl, SMC, HAYNES, VDM, ArcelorMittal, Outokumpu, etc.Q: What are your company's payment methods? A: 30% T/T deposit, 70% T/T balance payment before shipment. More payment methods depend on your choices. Q: Can you accept small orders? A: If we have the exact materials in stock, we can deliver even 1 piece. If we don't have the goods in stock, the MOQ is normally 1 ton.Q: Do you guarantee the safe and reliable delivery of products? A: Yes, we always use high-quality packaging for shipping. We usually pack the products with a soft material such as polyethylene foam and then pack it in wooden cases to ensure the safety of the product in the process of transportation.Q: Does ZYTC provide processing services? A: Yes, we also provide processing services to the outside world, and providing professional services is one of our goals. Such as bending, water cutting, laser cutting, digging holes, welded, slit coil, and other processing according to the drawings.Q: How to guarantee the quality? A: Each production procedure will be subject to test and evaluation. from the very choice of raw materials to the package for shipment. Only the products surviving all the tests are delivered for export.Q: What if there is a quality problem? A: We also keep a piece of the sample before shipping. After comparing the buyer's test result, and it turns out to be our problem, we will return the money back and pay for your lost or delivery of qualified materials again.Q: Can you provide samples? A: As a professional company, we know that the quality of products is valued by each customer, especially for international trade, we understand the customer's worries, so we can provide samples to customers, and we can ensure the consistency of the quality of samples and batch product products. The sample is free, but the buyer should pay the freight fee. And the freight fee will be returned in the future order.Q: How about the delivery time? A: Stock products can be shipped within 3 days. Customized product delivery time is normally 25 working days, but it is also influenced by the specific requirements or the order quantity. Partial shipment is allowed.

Trademark	GB	GOST	ASTM	UNS
Hastelloy N	-	-	Hastelloy N	N10003

Rod, Bar, Wire and Forgings	ASTM B573, ASME SB573, AMS 5771
Plate, Sheet and Strip	AMS 5607, ASTM B434, ASME SB434
Pipe and Tube	-
Welding Product	ERNiMo-2 A5.14
Others	ASTM B366, ASME SB366

UNS	W. Nr	DIN
N10004

Hastelloy X specifications:

UNS	W. Nr
N06602	2.4665

Bar	Sheet/Strip	Wire	Pipe
ASTM B572	ASTM B435	ASTM B166	ASTM B622 ASTM B619 ASTM B626

Alloy

C

Si

Mn

P

S

Cr

Ni

Mo

W

Al+Ti

Cu

B

V

Fe

Hastelloy N

0.04-0.08

≤1.00

≤1.00

≤0.025

≤0.010

6.0-8.0

Bal

15.0-18.0

≤0.50

≤0.50

≤0.35

≤0.01

≤0.50

≤5.

Elements	Content (%)
Nickel, Ni	67
Chromium, Cr	14.5 - 17
Molybdenum, Mo	14 - 16.5
Iron, Fe	3
Cobalt, Co	2
Tungsten, W	1
Copper, Cu	0.35
Manganese, Mn	0.30 - 1.0
Silicon, Si	0.20 - 0.75
Aluminum, Al	0.10 - 0.50
Carbon, C	0.020
Phosphorous, P	0.020
Boron, B	0.015
Sulfur, S	0.015
Lanthanum, La	0.010 - 0.10

Alloy

C

Si

Mn

P

S

Cr

Ni

Co

Mo

W

V

Fe

Hastelloy W

≤0.12

≤1.00

≤1.00

≤0.04

≤0.03

4.0-6.0

Bal

≤2.5

23.0-26.0

≤1.00

≤0.06

4.0-7.0

Composition		Ni	Cr	Fe	Mo	W	Co	C	Mn	Si	S	Cu	Al	Ti
Content (%)	Min.	Bal.	20.5	17.0	8.0	0.2	0.5	0.05
	Max.		23.0	20.0	10.0	1.0	2.5	0.15	1.0	1.0	0.015	0.5	0.15	0.5

Density, g/cm3	Melting Point, ºC	Tensile Strength, MPa	Yield Strength, MPa	ELongation, %	Hardness, HRB
8.86	1300-1400	462	148	47	/

Density, g/cm3	Melting Point, ºC	Tensile Strength, MPa	Yield Strength, MPa	ELongation, %	Hardness, HRB
9.00	1290-1375	965	520	51	/

Tensile Strength (σb/MPa)	Yield Strength (σp0.2/MPa)	Elongation (σ5/%)
690	275	30

Nickel Sheet
Thickness	0.3mm - 6.0mm
Width	1000mm - 2200mm
Length	Produce as requirement
Nickel Plate
Thickness	3.0mm - 300mm
Width	1000mm - 3000mm
Length	Produce as requirement
Nickel Strip / Nickel Foil
Thickness	0.02mm - 16.0mm
Width	5mm - 900mm
Nickel Coil
Thickness	0.3mm - 16.0mm
Width	1000mm - 3000mm
Nickel Pipe
Outside Diameter	6.0mm - 1219mm
Thickness	0.5mm - 100mm
Nickel Capillary Pipe
Outside Diameter	0.5mm - 6.0mm
Thickness	0.05mm - 2.0mm
Nickel Bar
Diameter	Ф4mm - Ф600mm
Nickel Wire Rod
Diameter	Ф0.01mm - Ф6.0mm
Material Classification
Inconel	Inconel 722, Inconel 725, Inconel X-750, Inconel 625, Inconel 686, Inconel 690, Inconel 702, Inconel 706, Inconel 713C, Inconel 600, Inconel 601, Inconel 602CA, Inconel 617, Inconel 718.
Incoloy	Incoloy 945, Incoloy A-286, Incoloy 901, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy 926, Incoloy 330, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 801, Incoloy 840, Incoloy 20, Incoloy 205, Incoloy 208
Hastelloy	Hastelloy C 276, Hastelloy G, Hastelloy W, Hastelloy X, Hastelloy G-30, Hastelloy G-35, Hastelloy G3, Hastelloy N, Hastelloy S, B-2, Hastelloy B-3, Hastelloy C2000, Hastelloy C22
Haynes	Haynes 75, Haynes 244, Haynes 25, Haynes 263, Haynes 282, Haynes 556, Haynes 188, Haynes 230, Haynes 233, Haynes 242
Monel	Monel 400, Monel K-500, Monel R405, Monel 401, Monel 404, Monel 405.
Nimonic	Nimonic 91, Nimonic C263, Nimonic PE11, Nimonic PE16, Nimonic PK33, Nimonic 80A, Nimonic 96, Nimonic 90, Nimonic 901, Nimonic 105, Nimonic 115
Other Nickel	Waspaloy, Multimet N155, Mumetal 80, Rene 41, Kovar, Maraging 250, Maraging 300, Maraging 350, MP159, MP35N, Alloy 46, Alloy 48, Alloy 52, Alloy 42, Alloy 45, Cobalt alloy 6b, Custom 455, Invar 36, Invar 42, Nickel 200, Nickel 201
